Anti-ROBO1 [IPI-ROBO1.81] in Immunohistochemistry (Mouse)

Addgene #251704

Data Submitted By
Yvrick Zagar and Alain Chédotal
Lab Name
Alain Chédotal, Centre de Recherche Institut de la Vision
Submission Date
February 06, 2026
Publication Date
March 11, 2026 (modified March 13, 2026)
DOI
https://doi.org/10.57733/addgene.42v0e6
Abstract
Experimental results for Anti-ROBO1 [IPI-ROBO1.81] (Addgene #251704) in an immunohistochemistry (IHC) application on mouse spinal cord.
Citation
Anti-ROBO1 [IPI-ROBO1.81] in Immunohistochemistry (Mouse). Zagar Y, Chédotal A 2026. Addgene Report, https://doi.org/10.57733/addgene.42v0e6
Caption: Immunohistochemistry was performed on cryostat sections of thirteen-day old mouse embryos (E13) utilizing Anti-ROBO1 [IPI-ROBO1.81] (Addgene #251704) (right image) or goat anti-Robo1 (1:500; R&D Systems, #AF1749) as a positive control (left image), followed by species-specific secondary antibodies directly conjugated to Cy-3 fluorophores (Jackson ImmunoResearch #705-165-152 and #711-165-152 147 for goat anti-Robo1 and IPI-ROBO1.81, respectively). Sections were imaged with a fluorescent microscope (DM6000, Leica) coupled to a CoolSnapHQ camera (Roper Scientific).
Image attribution: Institute for Protein Innovation (IPI)

This report is made available under the Creative Commons Attribution 4.0 International License.

Antibodies Used
Anti-ROBO1 [IPI-ROBO1.81]
Addgene #251704
Cy3 AffiniPure Donkey Anti-Rabbit IgG (H+L)
Jackson ImmunoResearch #711-165-152

Materials & Methods

Sample

Target Species
Mouse
Cell / Tissue Type
Spinal cord
Additional Information
20μm spinal cord sections of thirteen-day old mouse embryo (E13)

Fixative

Fixative
Paraformaldehyde 4% in 0.12 M phosphate buffer, pH 7.4 (PFA)
Time
Overnight
Temperature
4 ˚C

Permeabilization / Delipidation

Agent
Triton X-100
Concentration
0.50%
Time
1 h
Temperature
Room Temperature

Blocking

Agent
Gelatin
Concentration
0.2% in PBS containting 0.5% Triton X-100
Time
1 h
Temperature
Room Temperature

Primary Antibody

Name
Anti-ROBO1 [IPI-ROBO1.81]
Source
Addgene
Catalog Number
251704
Host Species
Rabbit
Target Antigen
ROBO1
Concentration
5 µg/mL (1:200 dilution)
Time
Overnight
Temperature
Room Temperature
View in Addgene Catalog

Secondary Antibody

Name
Cy3 AffiniPure Donkey Anti-Rabbit IgG (H+L)
Source
Jackson ImmunoResearch
Catalog Number
711-165-152
Concentration
1:500 from 1.5 mg/mL stock
Time
120 min
Temperature
Room Temperature

Additional Information

Additional Information

Thirteen-day old mouse embryos (E13) were fixed by immersion in 4% paraformaldehyde in 0.12 M phosphate buffer, pH 7.4 (PFA) overnight at 4 °C. Samples were cryoprotected in a solution of 10% sucrose in 0.12 M phosphate buffer (pH7.2), frozen in isopentane at 50 °C, and then cut at 20 μm with a cryostat (Leica). Immunohistochemistry was performed on cryostat sections after blocking in 0.2% gelatin in PBS containing 0.5% Triton X-100 (Sigma). Sections were then incubated overnight with the following primary antibodies: goat anti-Robo1 (1:500; R&D Systems, #AF1749) or IPI-ROBO1.81 followed by 2 h incubation in species-specific secondary antibodies directly conjugated to Cy-3 fluorophores (Jackson ImmunoResearch #705-165-152 and #711-165-152 147 for goat anti-Robo1 and IPI-ROBO1.81, respectively). Sections were imaged with a fluorescent microscope (DM6000, Leica) coupled to a CoolSnapHQ camera (Roper Scientific).

Controls
Positive control: Commercial Robo1 antibody (R&D Systems, #AF1749)

Results

Result
Pass (The antibody worked under these conditions)
Describe Results
Signal corresponds to that of positive control antibody. Some background staining is observed.
