Anti-ROBO1 [IPI-ROBO1.81] in Immunohistochemistry (Mouse)
Addgene #251704
- Data Submitted By
- Yvrick Zagar and Alain Chédotal
- Lab Name
- Alain Chédotal, Centre de Recherche Institut de la Vision
- Submission Date
- February 06, 2026
- Publication Date
- March 11, 2026 (modified March 13, 2026)
- DOI
- https://doi.org/10.57733/addgene.42v0e6
- Abstract
- Experimental results for Anti-ROBO1 [IPI-ROBO1.81] (Addgene #251704) in an immunohistochemistry (IHC) application on mouse spinal cord.
- Citation
-
Anti-ROBO1 [IPI-ROBO1.81] in Immunohistochemistry (Mouse). Zagar Y, Chédotal A 2026. Addgene Report, https://doi.org/10.57733/addgene.42v0e6
Image attribution: Institute for Protein Innovation (IPI)
This report is made available under the Creative Commons Attribution 4.0 International License.
- Antibodies Used
-
Anti-ROBO1 [IPI-ROBO1.81]
Addgene #251704 -
Cy3 AffiniPure Donkey Anti-Rabbit IgG (H+L)
Jackson ImmunoResearch #711-165-152
Materials & Methods
Sample
- Target Species
- Mouse
- Cell / Tissue Type
- Spinal cord
- Additional Information
- 20μm spinal cord sections of thirteen-day old mouse embryo (E13)
Fixative
- Fixative
- Paraformaldehyde 4% in 0.12 M phosphate buffer, pH 7.4 (PFA)
- Time
- Overnight
- Temperature
- 4 ˚C
Permeabilization / Delipidation
- Agent
- Triton X-100
- Concentration
- 0.50%
- Time
- 1 h
- Temperature
- Room Temperature
Blocking
- Agent
- Gelatin
- Concentration
- 0.2% in PBS containting 0.5% Triton X-100
- Time
- 1 h
- Temperature
- Room Temperature
Primary Antibody
- Name
- Anti-ROBO1 [IPI-ROBO1.81]
- Source
- Addgene
- Catalog Number
- 251704
- Host Species
- Rabbit
- Target Antigen
- ROBO1
- Concentration
- 5 µg/mL (1:200 dilution)
- Time
- Overnight
- Temperature
- Room Temperature
Secondary Antibody
- Name
- Cy3 AffiniPure Donkey Anti-Rabbit IgG (H+L)
- Source
- Jackson ImmunoResearch
- Catalog Number
- 711-165-152
- Concentration
- 1:500 from 1.5 mg/mL stock
- Time
- 120 min
- Temperature
- Room Temperature
Additional Information
- Additional Information
Thirteen-day old mouse embryos (E13) were fixed by immersion in 4% paraformaldehyde in 0.12 M phosphate buffer, pH 7.4 (PFA) overnight at 4 °C. Samples were cryoprotected in a solution of 10% sucrose in 0.12 M phosphate buffer (pH7.2), frozen in isopentane at 50 °C, and then cut at 20 μm with a cryostat (Leica). Immunohistochemistry was performed on cryostat sections after blocking in 0.2% gelatin in PBS containing 0.5% Triton X-100 (Sigma). Sections were then incubated overnight with the following primary antibodies: goat anti-Robo1 (1:500; R&D Systems, #AF1749) or IPI-ROBO1.81 followed by 2 h incubation in species-specific secondary antibodies directly conjugated to Cy-3 fluorophores (Jackson ImmunoResearch #705-165-152 and #711-165-152 147 for goat anti-Robo1 and IPI-ROBO1.81, respectively). Sections were imaged with a fluorescent microscope (DM6000, Leica) coupled to a CoolSnapHQ camera (Roper Scientific).
- Controls
- Positive control: Commercial Robo1 antibody (R&D Systems, #AF1749)
Results
- Result
- Pass (The antibody worked under these conditions)
- Describe Results
- Signal corresponds to that of positive control antibody. Some background staining is observed.
