Anti-CNTN2 (TAG-1) [IPI-CNTN2.57] in immunohistochemistry (IHC) (mouse)

Addgene #254655

Data Submitted By
Alexander Morano , Travis Riedel and Deborah Moshinsky
Lab Name
Institute for Protein Innovation (IPI)
Submission Date
April 16, 2026
Publication Date
May 12, 2026 (modified May 14, 2026)
DOI
https://doi.org/10.57733/addgene.3v1rxy
Abstract
Experimental results for Anti-CNTN2 (TAG-1) [IPI-CNTN2.57] (Addgene #254655) in an immunohistochemistry (IHC) application on mouse spinal cord.
Citation
Anti-CNTN2 (TAG-1) [IPI-CNTN2.57] in immunohistochemistry (IHC) (mouse). Morano A, Riedel T, Moshinsky D 2026. Addgene Report, https://doi.org/10.57733/addgene.3v1rxy
Caption: Immunohistochemistry (IHC) of a 20 micron cryosection of the spinal cord of an E13 mouse embryo. Confocal images taken at 20X magnification on an ImageXpress confocal HT.ai microscope. Left image shows Anti-CNTN2 (TAG-1) [IPI-CNTN2.57] (Addgene #254655) (magenta), neuronal counterstain NeuN (green), and DAPI (blue); the right image only shows IPI-CNTN2.57. IPI-CNTN2.57 was used at 10 µg/mL (1:100 dilution).
Image attribution: Institute for Protein Innovation (IPI)

This report is made available under the Creative Commons Attribution 4.0 International License.

Antibodies Used
Anti-CNTN2 (TAG-1) [IPI-CNTN2.57]
Addgene #254655
Goat anti-rabbit alexa fluor 647
ThermoFisher #A21245

Materials & Methods

Sample

Target Species
Mouse
Cell / Tissue Type
Spinal cord
Additional Information
E13 mouse embryo

Buffer

Name
PBS

Fixative

Fixative
Paraformaldehyde, 4% in PBS
Time
1.5 hours post-fixation with PFA after perfusion and harvesting
Temperature
4 ˚C

Permeabilization / Delipidation

Agent
PBS with 0.1% Triton-X 100
Time
15 min (3x 5 min washes)
Temperature
Room Temperature

Blocking

Agent
Normal Goat Serum
Concentration
5% in PBST
Time
60 min
Temperature
Room Temperature

Primary Antibody

Name
Anti-CNTN2 (TAG-1) [IPI-CNTN2.57]
Source
Addgene
Catalog Number
254655
Host Species
Rabbit
Target Antigen
CNTN2
Concentration
10 µg/mL (1:100 dilution)
Time
60 min
Temperature
Room Temperature
View in Addgene Catalog

Secondary Antibody

Name
Goat anti-rabbit alexa fluor 647
Source
ThermoFisher
Catalog Number
A21245
Concentration
1:500 dilution from a 2 mg/mL stock
Time
90 min
Temperature
Room Temperature

Additional Information

Additional Information

Immunohistochemistry Methods: Mouse embryonic spinal cord

Mouse embryos were first purchased from Jackson Labs. Instructions were provided to Jackson labs for harvesting and fixing tissue. Immediately after harvesting by C-section, embryos were fixed in 4% PFA in 1X PBS for 2 h at 4 °C, then washed 3x 10 minutes in 1X PBS, then stored in 1X PBS + 0.01% sodium azide at 4 °C.

Equilibrated tissue was then frozen in OCT on dry ice and 20–25 μm sections were cut on a Leica cryostat at the Harvard histology/sectioning core. Slides were thawed for 5 min at RT; sections were rehydrated 1x 5min in 1X PBS and then washed 3x 5 min in 1X PBST (0.1% Triton X-100 in 1X PBS) in a humidified chamber in a slide box. Slides were blocked for 1 h at RT in 5% NGS (Normal Goat Serum) or 5% NDS (Normal Donkey Serum) in 0.1% Triton-X-100 in PBS. Primary antibodies were then diluted in blocking solution and incubated for overnight at 4 °C. Slides were then washed 4x 5min in 0.1% TritonX-100 and incubated with secondary antibodies diluted in blocking solution (5% NGS or NDS) at RT for 1.5–2 h, in the dark. Slides were washed 4x 5 min in 0.1% TritonX-100 again, then 1x 5min in 1X PBS. Slides were then mounted in Fluoromount mounting medium with DAPI, outlined with nail polish to secure the coverslip, and stored at 4 °C in the dark until ready to image.

Controls

Positive control: NeuN counterstain (anti-mouse IGG1).

Negative control (not shown): no primary control.

Results

Result
Pass (The antibody worked under these conditions)
Describe Results
This antibody shows strongest staining along the commissural axons, particularly as they cross the floor plate, in accordance with extant literature describing the localization of CNTN2/TAG-1.
